14EH
Heavy Duty Tandem Axle Seamless I-Beam Equipment Trailer
Part of the all-new X-Series, the 14EH Equipment Trailer from Big Tex Trailers is engineered for professionals who demand durability and innovation. The 14EH features a Mega-Sized Toolbox for added storage capacity. It's enhanced with a Full-Length Rub Rail, D-Rings, and Stake Pockets, providing multiple secure tie-down options for a variety of cargo. The 14EH revolutionizes loading and unloading with its optional Self-Stabilizing Mega Ramps, offering unparalleled flexibility for all your hauling needs.
With you for the long haul™
| Standard Feature | Available Options | |
|---|---|---|
| Axles | 2 - 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs | |
| Brakes | Forward Self-Adjusting Electric Brakes on All Hubs | |
| Suspension | Multi-Leaf Slipper Spring w/ Equalizer | |
| Coupler | Adjustable 2-5/16” Demco EZ Latch | Adjustable Pintle in Channel in Lieu of Coupler Adjustable 2-5/16" Demco EZ Latch Gooseneck Coupler |
| Safety Chains | 3/8" Grade 70 w/ Safety Latch Hook (2 ea) | |
| Jack | 12,000# Drop-Leg Jack (Side Wind) | |
| Frame | 8" I-Beam | |
| Cross-Members | 3" Channel on 16" Centers | |
| Front Stop Rail | 3/16" Fabricated Front Stop Rail | |
| Floor | Treated Pine Floor | |
| Fenders | 9” x 72” 14 Ga. Diamond Plate Double Square Broke w/Back (Removable) | |
| Ramps | 5' Tall, 16" Stand Up Rams (Spring Assisted) | 36" Wide Mega Ramps (D3 Models Only) Super-Wide Ramps (60" Tall x 30" Wide) w/ Blackwood Pro-Filled Dovetail |
| Dovetail | 40” Cleated Dovetail | |
| Stake Pockets | Stake Pockets Along Both Sides (Quantity Varies by Length) | |
| Trailer Plug | 7-Way RV | |
| Lights | L.E.D. D.O.T. Stop, Tail, Turn & Clearance | |
| Wiring | Sealed, Modular Cold-Weather Wiring Harness | |
| Tires | ST235/80 R-16 Load Range E Radial Tires | Tire Upgrade (ST235/80 R-16 LR-G) |
| Bolt Pattern | 8-Lug | |
| Spare Mount | Front Spare Tire Mount | |
| Spare Tire | Not Included | Spare Tire & Wheel (ST235/80 R-16 LR-E) |
| Paint Color | Black | Red Grey White Desert Tan Jet Blue Slime Green Implement Green Equipment Orange Medium Yellow |
| Rubrail | Rub Rail Along Both Sides | |
| Tie-Downs | (6) 5/8" D-Rings | |
| Break-Away Kit | Complete Breakaway System w/ Zip Breakaway Cable | |
| Storage | Lockable Toolbox Between Risers on Gooseneck Model Mega-Sized Integrated Tongue Box with Lockable Lid (Bumper Pull Only) | |
| Steps & Handles | Convenient Side-Step to Access Deck |
| Model | Pull Type | GVWR | GAWR (Ea. Axle) | Tail Type | Empty Weight | Cargo Capacity | Bed Length | Bed Width | A | B | C |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 14EH-16D3A | Bumperpull | 15400 lbs | 7000 lbs | Dovetail | 2640 lbs | 12760 lbs | 16' | 83" | 192" | 110" | 82" |
| 14EH-18D3A | Bumperpull | 15400 lbs | 7000 lbs | Dovetail | 2840 lbs | 12560 lbs | 18' | 83" | 216" | 129.5" | 86.5" |
| 14EHG-20D3A | Gooseneck | 15900 lbs | 7000 lbs | Dovetail | 3322 lbs | 12578 lbs | 20' | 83" | 240" | 144" | 96" |
| 14EH-20D3A | Bumperpull | 15400 lbs | 7000 lbs | Dovetail | 3040 lbs | 12360 lbs | 20' | 83" | 240" | 144" | 96" |
| 14EHG-22D3A | Gooseneck | 15900 lbs | 7000 lbs | Dovetail | 3522 lbs | 12378 lbs | 22' | 83" | 264" | 158.5" | 105.5" |
| 14EH-22D3A | Bumperpull | 15400 lbs | 7000 lbs | Dovetail | 3240 lbs | 12160 lbs | 22' | 83" | 264" | 158.5" | 105.5" |
| 14EHG-24D3A | Gooseneck | 15900 lbs | 7000 lbs | Dovetail | 3722 lbs | 12178 lbs | 24' | 83" | 288" | 173" | 115" |
| 14EH-24D3A | Bumperpull | 15400 lbs | 7000 lbs | Dovetail | 3440 lbs | 11960 lbs | 24' | 83" | 288" | 173" | 115" |
WARNING: This product can expose you to chemicals including Arsenic (inorganic arsenic compounds) which is known to the State of California to cause cancer and Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
